Yamaha CrossConnect

Yamaha CrossConnect
This item is currently not available.


Your daily trek isn’t like others. You’re surrounded by hills and you demand more than just a regular fitness bike. You want the efficiency of a road bike, ergonomic comfort of a flat handlebar, and power assist technology that allows you to charge the day. Grab your CrossCore and live Generation Go!

- Yamaha hydroformed and butted aluminum frame
- SR Suntour NCX 63mm suspension fork
- 700c wheel set
- 18-speed Shimano Sora components
- Shimano M315 hydraulic disc brakes
- PWSeries SE motor
- LED Headlamp and tail light

WARNING: This product can expose you to chemicals known to the state of California to cause cancer and birth defects or other reproductive harm. For more information, go to


Motor PWSeries SE, Center mount, Square taper spindle, Triple Sensor System with integrated speed sensor as part of rear hub, Weight: 7.71lb Rated power: 250W (Nominal), 500W (Max) Max torque: 70Nm Max cadence support: 110rpm Max speed support: 20mph, Support modes: ECO+, ECO, STANDARD, HIGH
Battery Yamaha 500Wh with Charge-life indicator and self-diagnosis display, Side-exiting dock station with anti-vibration mounting plate, Weight 6.61lb, 500Wh 36V, 4-hour charge time
Display Cycling function display include: speed, average speed, maximum speed, trip distance, odometer, cadence, battery capacity
Max Assisted Speed 20mph
Charger Yamaha battery charger
Frame Yamaha hydroformed and butted aluminum tubing, Internal cable/housing routing, Accessory mount 3-bolt motor mount 12 x 142 rear spacing, Integrated speed sensor harness
Fork SR Suntour NCX 63mm, mechanical lock-out, 30mm stanchion, magnesium lowers, adjustable air sleeve Alloy 1 1/8in steerer, 15mm thru-axle Fender included
Headset Integrated headset with 30mm headset spacers
Axles Front: 12x100mm Thru-Axle Rear: 12x142mm
Rims/Wheels 700c. Dual channel welded pin rim Eyelet spoke holes
Hubs Anodized, Shimano freehub and Yamaha Bicycles Speed Sensor
Spokes Spokes SUS304
Tires CST E-SERIES PRO 28×1 5/8 ×1 3/8(700 x 35c), Level-6 Flat Protection Reflective Sidewall approved for eBike use PV Tube
Chainrings 46/34T 110 BCD
Chain KMC X9e
Front Derailleur Shimano Sora (2 x 9) Braze-on
Rear Derailleur Shimano Sora RD-3000 GS 9-speed
Cassette/Rear Cogs Shimano 9-speed 11/30T
Shifters Shimano 9-speed Sora trigger shifter.
Handlebars Alloy flat bar zero degree rise. 31.8mm diameter. 640mm width.
Tape/Grips Locking ergonomic two-tone
Stem Yamaha Alloy 4-bolt faceplate 31.8 diameter 80mm length (54cm, 56cm) 100mm length (58cm)
Brakes Shimano M315 Hydraulic Disc 160mm Front:6-bolt SM-RT 56 Rotor. Rear: Shimano SM-RT68 Centerlock Rotor
Saddle Yamaha Path Plus Cro-Mo Rails
Seatpost Alloy 30.9 x 260mm (S), 315mm (M), 350mm (L) with 2-bolt adjustable tilt saddle rail clamp
Accessories & Extras Yamaha keys, Yamaha battery charger, LED Headlamp, Bell rear rack with front/rear fenders and integrated LED tail light

* Subject to change without notice.
